5 Test Functions
5.6 WiFi Status

Access only when a WLAN adapter is installed!
The WiFi status function prints out a list the most important parameters of the accessible Wireless Access Points.
The printout occurs using the heat level and print speed specied in the Setup > Print param. menu.
i
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start Ofine menu.
 Select Test > WiFi status.
The printout can be cancelled with
.
WiFi status
Fri Sep 23 12:53:54 2011
EOS1/300
Firmware V4.02 (Sep 21, 2011) - #170110417590
Channel Name/BSS ID Signal level Encryption
1 default
●●●●●
WPA-PSK-TKIP
00:24:b2:36:98:60
1 cab-firma
●●●●●
WPA-PSK-TKIP
00:24:b2:36:98:61
1 cab-gast
●●●●●
WPA-PSK-TKIP
00:24:b2:36:98:62
11 default
●○○○○
WPA-PSK-TKIP
00:24:b2:36:98:60
11 cab-firma
●○○○○
WPA-PSK-TKIP
00:24:b2:36:98:61
11 cab-gast
○○○○○
WPA-PSK-TKIP
00:24:b2:36:98:62
Fig. 14 WiFi status
The parameters have the following meaning :
Column Meaning
Channel Channel; frequency range of the Access Point
Name/BSS ID
Name of the wireless LAN
MAC address of the Access Points
Signal level Scale of the WiFi signal strength
Encryption Type of data encryption
Table 14 Parameters of the WiFi status
