36
ENGLISH
UK
Sistema Caberg Just Speak Per Sintesi/Sintesi Jet/Hyperx
1) Remove the inner lining and check pads.
2) Remove the cover on left side of the shell by
pushing forward the cursor.
3) Slip on the connector with 8 poles between
the EPS and the shell in order that the cable co-
mes out from the apposite slit. Connect the key
pad with the Connector and place it in its sea-
ting on the shell .
4) Fix the microphone arm in its apposite se-
ating A.
5)Make sure that the word STILO on the micro-
phone head is oriented towards your mouth.
2 INSTALLATION
