Token Ring Configuration
SynOptics Token Ring NMM Topology Table View
Configuration Views SynOptics Series 3000 Hub
3-14 Management Module Guide
SynOptics Token Ring NMM Topology Table View
This view provides a list of all the active MAC addresses that are currently
connected to a specified segment identified by an interface on an NMM, and
are directly connected to a host port on the chassis or are a MAC on a board in
the chassis. The NMM Table view provides the following information:
Module
The module number.
Address
The physical (MAC) address.
Vendor
The vendor of the device connected to that port. This is determined from the
MAC address.
SynOptics Token Ring NMM Configuration View
This view provides the following configuration information for this device:
Module
The number of the slot containing the module.
Network
You may enter the flat network number that this NMM is part of.
Segment
The segment number (in the concept of Token Ring the segment means the
ring) that this NMM is connected to.
Ring Status
The status of the ring.
Ring
The identifying number of the ring.
Ring Speed
The speed at which the hub is configured to operate.
FPU Revision
The revision number of the front end processing unit.
FPU Status
The status of the front end processing unit.
DRAM Size
The highest address of DRAM in the NMM memory map.
EEPROM Size
The size of the EEPROM in the NMM memory map.
