Instrumentation and Controls
. . . 158
4. First push the left latch toward
the front of the vehicle to lock
the panel in place and then
secure the right latch.
The latches should click when
they are locked securely.
5. Using the same procedure,
install cargo panel marked
2 and then panel marked 3.
When locking the latches,
always lock the left latch
before locking the right latch.
Cargo Panel Storage System
The three cargo panels can be
stored in the cargo area using the
storage straps.
Always use the storage straps to
store the cargo panels while
driving the vehicle.
x 2
