Section 4
17 Air Conditioning Compressor
18 Oxygen Sensors
19 Transmission Controls (Ignition)
20 Fuel Pump
21 Fuel System Control Module
22 Horn
23 Not Used
24 Fuel Injectors; Ignition Coils
(Left Side)
25 Trailer Parking Lights
26 Left Parking Lights
27 Right Parking Lights
28 Fog Lights
29 Horn
30 Right High-Beam Headlight
Fuses Usage
31 Not Used
32 Left High-Beam Headlight
33 Not Used
34 Sunroof
35 Key Ignition System; Theft Deterrent
System
36 Windshield Wiper
37 Not Used
38 Electric Adjustable Pedals
39 Climate Controls (Battery)
40 Air Bag System (Ignition)
41 Amplifier
42 Sound System
43 Miscellaneous (Ignition); Cruise
Control
44 Not Used
Fuses Usage
Underhood Electrical Center (Continued)
