Cadillac XTS - Vehicle Top Speed; Engine Drive Belt Routing

Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
300 TECHNICAL DATA
Engine Specifications
Engine VIN Code Horsepower Torque Spark Plug Gap
3.6L V6 Engine (LF3) 8 306 kW @ 6000 rpm
(410 hp @ 6000 rpm)
500 Y @1900–
5600 rpm
(369 lb ft @ 1900–
5600 rpm)
0.75–0.90 mm
(0.030–.035 in)
3.6L V6 Engine (LFX) 3 227 kW @ 6800 rpm
(305 hp @ 6800 rpm)
264 Y @5200 rpm
(358 lb ft @ 5200 rpm)
0.95–1.10 mm
(0.037–.043 in)
Vehicle Top Speed
Vehicle Top Speed Metric English
3.6L V6 Engine (LF3) 219 km/h 136 mph
3.6L V6 Engine (LFX) 209 km/h 130 mph
