2.2. Main characteristics
3-coaxial piston cylinder …………………............ Double acting
Air supply connection.......................................... G 1/8 cylindrical threaded hole
Use dry, lubricated air …………………………….
Operating air pressure ……………...................... 5 to 6 bar
360°rotating head …………………………………
Cylinder operated by trigger ……………………..
Weight of cylinder alone ………………………..... 0.600 kg
Weight of complete cylinder (w/o cable) ….……. 0.720 kg
Emitted vibrations ………………………………. < 2.5 m/s²
Noise level …………………………….………….< 70 dBA
2.3. Dimensions
Short head
Half-long head
