FICHE D’INSTRUCTION TECHNIQUE
N°
: V 54 1006
PINCE PNEUMATIQUE CLIC COMPACTE
CLIC PNEUMATIC PLIER
S
CLIC DRUCKLUFTZANGE
PINZA PNEUMATICA CLI
C
PINZA NEUMATICA CLIC
Date : 07/11/2017
Indice
: C
Page 8/16
2.7. Removing the clamp
2.8. Classification
If you need more information contact your CAILLAU agent or consult the catalogue to get the
reference that you need.
Disassembly pliers
540000205
Close the pliers to release the latch
from the ear.
Once the latch is released,
withdraw
the pliers and
remove
the clamp from the
application
.
Figure 2: CAILLAU tool’s catalogue
