HELiOS Portables Technical Service Manual • PN 20562190 Rev E
56
HELiOS Portables
Service Tools/Equipment/Supplies
XV
For a complete list of accessories, see the accessories catalog on www.cairemedical.com.
Table #10
Table #9 Table #11
Required Supplies
Household Glass Cleaner
Krytox Lubricant
Lint-Free Cloth
Snoop Liquid Leak Detector
TEFLON Tape
Scotch Brite Adhesive Pad
Required Tools
Adjustable Wrench – 10 inch
Adjustable Wrench – 8 inch
Clamp or Hemostat
Dental Pick
Flat Head Screwdriver
Hex (Allen) Wrenches - Various Sizes
Jewler’s Screwdriver
Micro Bar Clamp
Needle Nose Pliers
Open Ended Wrench – 1/2 inch
Open Ended Wrench – 1/4 inch
Open Ended Wrench – 5/8 inch
Open Ended Wrench – 7/16 inch
Open Ended Wrench – 9/16 inch
Phillips Head Screwdriver
Side Cutters
T10 Torx Driver
Tie Wraps
Required Fixtures/Equipment
Calibrated Flow Meter
Calibrated Weight Scale
Jet Venturi Assembly
Liquid Oxygen Source
Portable Test Fixture
Test Pressure Gauge w/ Tubing
Gaseous Oxygen Source 0-6.89 bar (0-100 psi)
Oxygen Compatible Tubing – 3/16 inch (0.48 cm) diameter
Tee Connector – 3/16 inch (0.48 cm)
