TS3 Lite Diagram
AC Adapter
USB 3.1 Type-C
(Data & Charge)
USB 3. 1
Type-A
USB 3. 1
Type-A
DisplayPortThunderbol t™ 3Gigabit
Ethernet
Audio
Out
Audio
In
Computer with
Thunderbolt™ 3
Pen Drive External Drive
4K
Monitor
Wall Outlet4K/5K
Monitor
External Storage
