10
Interface Summary
USB 3.1 Type-A
The TS3 Plus features a total of ve USB 3.1 Type-A ports (4 x 5Gb/s, 1 x 10Gb/s)
Thunderbolt™ 3
The TS3 Plus features two Thunderbolt™ 3
Type-C ports that can transfer at speeds up to
40Gb/s. One port is reserved for the connection
to your host computer and the second can be
used to connect extra Thunderbolt™ 3 devices.
Thunderbolt™ 3 Type-C supports video and
data. The Thunderbolt™ host port also provides
charging up to 85W for your computer.
USB 3.1 Type-C
The TS3+ features two USB 3.1 Type-C ports (1 x 5Gb/s, 1 x 10Gb/s). These ports only support data
and 900mW of power for charging. Video capabilities are not supported.
UHS-II SD Card Slot
The front-facing UHS-II SD (4.0) Card slot is
capable of transfer speeds up to 312MB/s.
This slot is also backwards compatible with
SDXC, SDHC, and standard SD cards.
Optical Audio (S/PDIF)
The TS3+ features one optical audio port
that can be used to connect a compatible AV
receiver using TOSLINK cables..
Front (x1)
Front (x1)
Rear(x1)
Rear(x4)
