CalDigit TS3 Plus - CalDigit TS3 Plus Specifications

14
CalDigit TS3 Plus Specications
Package Dimension and Weight
• Height : 5.15 inches (131.0 mm)
• Width : 1.57 inches (40.0 mm)
• Depth : 3.87 inches (98.44 mm)
• Weight: 1.04 lbs (0.47 kgs)
Interface
• 2 x Thunderbolt™ 3
• 1 x DisplayPort 1.2
• 5 x USB 3.1 Type-A (Gen.1 5Gpb/s)
• 1 x USB 3.1 Type-C (Gen.2 10Gpb/s)
• 1 x USB 3.1 Type-C (Gen.1 5Gpb/s)
• 1 x SD Card Reader (SD 4.0 UHS-II)
• 1 x Digital Optical Audio (S/PDIF)
• 1 x Gigabit Ethernet
• 1 x 3.5mm Analog Audio In
• 1 x 3.5mm Analog Audio Out
Power
AC Input : 100V-240V ~50Hz/60Hz
DC Output: 20V/9.0A, 180W
System Requirements
Thunderbolt™ 3 computers
Mac OSX 10.12 or later
Windows 7, 8, 10 or later
Environment
Ambient Operating Temperature: 32°F ~ 158°F (0°C ~ 70°C)
