S320 OCS Hardware User Guide
Doc. Part No. 460167-00
May 27, 2015
Rev. B7
Page 20 of 46
Figure 1 S320 OCS Architecture
The core of the S320 OCS is the MSM, which establishes the light paths. The light path within
the MSM architecture is illustrated in Figure 2.
Figure 2 Light Path within the MSM
Fibers mounted
in a Fiber Block
Fibers mounted
in a Fiber Block
Fibers mounted
in a Fiber Block
Fibers mounted
in a Fiber Block
Collimating Lens
Collimating Lens
Mirror Matrix
Mirror Matrix
Mirror Matrix
Mirror Matrix
