4.4.3 Environmental Requirements
Table 5 lists environmental requirements for storing and transporting the S320 OCS.
Table 5 – S320 OCS Environmental Requirements
Temperature
1
Operating
5° to 55° C (41° to 131° F)
Non-operating
-40° to 70° C (-40° to 158° F)
Shock
Max Rate of Change 20° C/min
Humidity
Operating
10-90% RH non-condensing
Non-operating
5-93% RH non-condensing
Altitude
Operating
Up to 1600 meters
Non-operating
Up to 12,000 meters
Vibration
Operating
a). GR-63 – x/y/z-axis: 5Hz-100Hz-5Hz at 0.1G
amplitude swept at 0.25 octaves/minute
b). 0.16Grms, 5 Hz to 250 Hz: 0.0001 g^2/Hz (flat)
Packaged (for
shipping)
ATSM composite Truck, Rail, Air. 5Hz-20Hz at
0.01g^2/Hz, 20-200Hz -3dB/octave
Shock
2
Operating
IEC 60068-2-27; +/- 3.5G, 11 msec, half-sine shocks
in the x, y, and z axes; run pre- and post-diagnostic
tests
Non-operating
IEC 60068-2-27; +/- 10G, 11 msec, half-sine shocks
in the x, y, and z axes; run pre- and post-diagnostic
tests
Drop
Unpackaged
Drop Test
GR-63 Unpackaged Drop: 3.0” on practical resting
surfaces
Packaged Drop
Test
GR-63 Packaged Category A Drop: 23.6”
GR-63 Packaged Category B (palletized) Drop: 3.9”
Dust
All fiber connector terminations must be cleaned and capped
1
The S320 will be certified to the criteria specified in NEBS-63, including the long-term and short-term
requirements detailed in Section 4.1.2 of NEBS-63.
2
Optical connections will be maintained throughout operation and then meet full optical specification
post-event.
