Wall Mount Screw Specifications
7 mm
.28 in
20 mm
.79 in
8317
2.6 mm
.1 in
3.75 mm
.15 in
#2
Depth
Mounting Screws
Depending on the material you are attaching to, use a screw of sufficient length and strength
to support the GigaSpire BLAST once attached to the bracket. See below for specifications
on what type of screw is recommended.
The two mounting holes on the back of the unit are designed to accommodate the following
screw type:
Larger than 7mm wide (.28") and less than 14mm wide (.55")
Screw shaft < 3mm in diameter (.12")
Screw length > 6mm (.24") and less than 20mm long. (.79")
