Power Off and Boot-up - RG Mode
Description Colors Indication
OFF
Power is Off
The unit has not been turned on
or
There is no power to the unit
or
Any auxiliary battery has been discharged and can
no longer power the unit.
Off
Booting Up, SW Upgrade in Process
Unit is in the process of booting up or
services/software is being upgraded
Flashing amber every 1 second assuming software
Off & Amber
Cycles @
1000 msec
Boot-up Failure
Unit boot-up has failed (assuming software can
Off & Red
Cycles @
Connected to the Internet
Unit has successfully booted up, local services are
up, and connected to Internet
Green
Service Failure - No Internet
No service, no internet access
Off & Red
Cycles @
