36
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
November 2022.
The unit must be powered by a listed power adapter or DC power source marked "LPS"
(Limited Power Source) and rated output between 12 VDC, 2 A minimum, TMA = 40°
C minimum. If additional help is needed on implementing a power supply, please contact
your local Calix service professional.
An external power supply is included with the following rating:
GigaSpire BLAST u4g
Input voltage: 100 - 240 VAC (nominal)
Output voltage: 10 VDC (min.), 15 VDC (max), 12 VDC (nominal)
External Power Adapter: 12 VDC, 2.5 A
DANGER! Using non-approved or incorrect power adapters can result in injury.
