Chapter 2: System Hardware
Table 112 Force 4625 series
–
rear interfaces
Power over Ethernet (PoE)
Optional 10 Gigabit SFP cage for SFP module
Force 4625 specifications
The Force 4625 integrated module conforms to the specifications listed in Table 113 and Table 114.
The integrated module meets the low-level static discharge specifications identified in Electromagnetic
compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning
suppression.
Table 113 Force 4625 physical specifications
Dimensions (Diameter x Depth)
256 mm x 125 mm x 46 mm (10.1 in x 4.9 in. x 1.8 in.)
Table 114 Force 4625 environmental specifications
-30°C to 65°C (-22°F to 149°F)
Force 4625 heater
At startup, if the Force 4625 module temperature is at or below 32°F (0°C), an internal heater is activated
to ensure that the device can successfully begin operation. The unit’s heater is only activated when the
unit is powered on and will not apply heat to the device once the startup is complete. When the unit
temperature is greater than 32°F (0°C), the heater is deactivated and the unit continues its start-up
sequence.
The effect on device startup time at various temperatures is defined in Table 115.
Table 115 Force 4625 startup times based on ambient temperature
Startuptime(frompowerontooperational)
