Chapter 2: System hardware System Components
Page 2-25
The AC+DC Enhanced Power Injector interfaces are shown in Figure 11 and described in Table 22. Figure 11 AC+DC
Enhanced Power Injector interfaces
Table 22 AC+DC Enhanced Power Injector interface functions
Interface
Function
100-240V 47-63Hz 1.5A
AC power input (main supply)
DC In
Alternative DC power supply input
DC Out
DC power output to a second PSU (for power supply redundancy) or to a NIDU
ODU
RJ45 socket for connecting Cat5e cable to ODU
LAN
RJ45 socket for connecting Cat5e cable to network
