PTP 550 QUICK START GUIDE
PAGE 6
o Ensure that equipment is installed in a position avoiding any radiation hazard to
humans.
• Exercise extreme care when working at heights. Observe national ‘working at heights’ regulations.
Use trained ‘competent’ staff.
• Exercise extreme care when working near power lines.
• PTP 550 devices and mounting structures must be properly grounded to protect against lightning. It
is the user’s responsibility to install the equipment in accordance with national regulations. It is
recommended that installation be contracted to a professional installer.
• Always use the specified PTP 550 platform power supply units (PSU) to power the equipment.
Failure to use the specified Cambium supplied PoE could result in equipment damage and may
cause a safety hazard.
• Structures, equipment and people must be protected against electrostatic discharge:
o by siting equipment in a lightning protection zone
o by installation of appropriate lightning conductors to conduct the surge current to
ground via a separate preferential solid path.
• The ODU enclosure may be hot to the touch when in operation.
• Safety may be compromised if outdoor rated cables are not used for connections that will be
exposed to the outdoor environment. Install Cambium recommended cables.
Kit Contents
Integrated ODU Kit Contents Connectorized ODU Kit Contents
• One 23 dBi integrated ODU
• One PSU of the type stated in the Cambium
description
• Mounting bracket
• One line cord (excluding C050055H012A), either
US (FCC), IC (ISEDC Canada) or EU (EU and RoW)
• One Connectorized ODU
• One ODU mounting bracket
• One PSU of the type stated in the Cambium
description
• One line cord (excluding C050055H006A),
either US (FCC), Canada (IC), or EU (EU
and RoW)
ODU interfaces
SFP
Main
Ethernet
