Cambridge Audio 640A - Input & Tone PCB BOM

Cambridge Azur Input and Tone PCB BOM AP131336
AP PART No. DRAWING
NO
DESCRIPTION QTY DESIGNATOR COMMENTS
AP12715/5 BARE INPUT PCB 1
220R 3W CARBON FILM RESISTOR 2 R61, R63
470R 1W CARBON FILM RESISTOR 2 R62, R64
680R 1W CARBON FILM RESISTOR 1 R55
56R 0.25W METAL FILM RESISTOR 2 R8, R9
100R 0.25W METAL FILM RESISTOR 14 R24, R25, R26, R29, R30, R31,
R34, R35, R36, R37, R38, R39,
R49, R51
4k7 0.25W METAL FILM RESISTOR 4 R2, R3, R42, R43
8k2 0.25W METAL FILM RESISTOR 4 R4, R11, R44, R45
10k 0.25W METAL FILM RESISTOR 8 R5, R7, R10, R12, R13, R14,
R46, R47
22k 0.25W METAL FILM RESISTOR 2 R1, R20
100k 0.25W METAL FILM RESISTOR 4 R15, R16, R18, R19
150k 0.25W METAL FILM RESISTOR 4 R52, R54, R59, R60
220k 0.25W METAL FILM RESISTOR 12 R6, R17, R21, R22, R23, R27,
R28, R32, R33, R40, R41, R50
5p CERAMIC 50/100V 5mm PITCH CAPACITOR 4 C9, C15
22p CERAMIC 50/100V 5mm PITCH CAPACITOR 4 C12, C13, C18, C21
330p POLY 50/100V 5mm PITCH CAPACITOR 2 C1, C10
47n POLY 50/100V 5mm PITCH CAPACITOR 12 C2, C3, C4, C5, C7, C8, C16,
C17, C19, C20, C24, C27
150n POLY 50/100V 5mm PITCH CAPACITOR 2 C6, C11
10u 35V NON POLAR ELECTROLYTIC CAPACITOR 6 C14, C25, C28, C29, C30, C31
100u 25V ELECTROLYTIC CAPACITOR 2 C32, C33
PY487 NJU 7313 AUDIO SWITCH IC 1 U1
PY108 NE5532 OP AMP 5 U2, U3, U4, U5, U6
4 WAY JST CONNECTOR 2.54mm PITCH 3 CN1, CN22
6 WAY JST CONNECTOR 2.54mm PITCH 1 CN3
ZUANBAO CK-6.35-08A (SILVER BEZEL)
HEADPHONE JACK
1 CN2
ZUANBAO AV2-8.4-9 GOLD DUAL PHONO SOCKET 1 CN4
ZUANBAO AV4-8.4-9 GOLD QUAD PHONO
SOCKET
4 CN10, CN11, CN12, CN13
6 WAY PIN HEADER 2.54mm PITCH 13mm LONG 2 CN7, CN8 AS PER EXISTING A500 INPUT PCB
DPDT WEALTH PBS-22HO1-T18-SL SWITCH 2 SW1, SW2
PY004 20k MOTORISED DUAL LOG POT RM16 WITH 22mm
LEGS
1 VR1
PY535 B20k LINEAR POT 2 VR2, VR3
PY005 MN20k BALANCE POT 1 VR4
LINK WIRE 24SWG 20mm LONG 30 LK1, LK2, ALL BLANK LINK
POSITIONS
M3 X 14 POZI PAN MACHINE SCREW BLACK 1 USED TO FIT OPTIONAL PHONO
STAGE
M3 LOCKWASHER 1 USED TO FIT OPTIONAL PHONO
STAGE
M3 NUT BLACK 2 USED TO FIT OPTIONAL PHONO
STAGE
AP13395/2 640A INPUT PCB TO SPEAKER PCB LOOM 1 CONNECT AS PER DRAWING TO
INPUT PCB BEFORE FITTING
INPUT PCB TO CHASSIS
AP10001/2 CAMBRIDGE AUDIO SCREENING CAN 1 EMBOSSED WITH ARTWORK
AP10018/1
12
