Cambridge Audio 640A - Speaker Output PCB BOM

Cambridge Azur Speaker Output PCB BOM AP131336
AP PART
No.
DRAWING
NO
DESCRIPTION QTY DESIGNATOR COMMENTS
SPEAKER TERMINAL OUTPUT PCB ASSEMBLY 1 POSITION ON REAR PANEL
AP12708/6b BARE SPEAKER TERMINAL PCB
2R2 3W WIREWOUND RESISTOR 2 R224, R264
1k 0.125W 1% METAL FILM RESISTOR 1 R33
10k 0.125W 1% METAL FILM RESISTOR 1 R32
PY536 MPSA13 DARLINGTON NPN TRANSISTOR 1 Q17
1N4004 RECTIFIER DIODE 1 D5
4 WAY JST CONNECTOR 2.54mm PITCH 1 CN3
LINK WIRE 24SWG 20mm LONG 2 LK24, LK25
PY594 12V 8A CONTACTS RELAY 1 RL1 FORWARD FRM10N 2C2S 12V 8A
USD0.61/10K --OR-- TYH HG4509 12V 8A
USD0.66/5K
25TURN 19AWG OUTPUT INDUCTOR 2 W201, W202 AS PER DRAWING: AP13772/1
ZUANBAO WP8-21A 8 WAY SPEAKER SOCKET 1 CN202 FITS UPSIDE DOWN SO BLACK AND RED
PEG COLOURS SHOULD BE INVERTED
29
