Cambridge Audio 640A - Mains Input PCB BOM

Cambridge Azur Mains Input PCB BOM AP131336
AP PART
No.
DRAWING
NO
DESCRIPTION QTY DESIGNATOR COMMENTS
MAINS INPUT PCB ASSEMBLY 1 FIXES IN THE CORRECT POSITION
ONTO THE PLASTIC PCB STANDOFFS
AP12712/8a BARE MAINS INPUT PCB 1
X2 680N SUPPRESSION 1 C2
1k 0.25W 1% METAL FILM RESISTOR 1 R25
10k 0.25W 1% METAL FILM RESISTOR 1 R26
10n CERAMIC X1 Y2 MAINS RATED CAPACITOR 2 C5, C6
PY536 MPSA13 NPN DARLINGTON TRANSISTOR 1 Q1
3V9 400mW ZENER DIODE 1 D11
1N4004 RECTIFIER DIODE 1 D10
METAL MAINS TERMINAL EYELETS 2 J13, J15 AS PER PCB AP11012/3
3 WAY JST CONNECTOR 2.54mm PITCH 1 CN4
IEC MAINS SOCKET PC1287 1 CN3 FIRST TECH AS PER D500 SE CD PLAYER
FUSE HOLDERS WITH SAFETY COVERS 5 FU1, FU2, FU3, FU4,
FU5
PY596 FUSE F1.6AL 2 FU4, FU5
PY361 FUSE F6.3AL 2 FU1, FU2
PY595 FUSE T3.15AL 1 FU3
PY594 12V 8A CONTACTS RELAY 1 RL1 FORWARD FRM10N 2C2S 12V 8A
USD0.61/10K --OR-- TYH HG4509 12V 8A
USD0.66/5K
M3 X 8 POZI PAN MACHINE SCREW 2 TO FIX IEC SOCKET TO MAINS PCB
M3 LOCKWASHERS 2 TO FIX IEC SOCKET TO MAINS PCB
M3 NUT 2 TO FIX IEC SOCKET TO MAINS PCB
AP13895/1 INSULATING SHEET 1 TO FIT UNDER PCB
