AP PART
No.
DRAWING NO DESCRIPTION QTY DESIGNATOR COMMENTS
4.7n CERAMIC 50/100V 5mm PITCH CAPACITOR 1 C27
15n POLY 50/100V 5mm PITCH CAPACITOR 2 C12, C14
47n POLY 50/100V 5mm PITCH CAPACITOR 10 C19, C20, C32, C40, C55,
C56, C57, C58, C67, C68
100n CERAMIC 50/100V 5mm PITCH CAPACITOR 10 C3, C4, C24, C28, C31,
C36, C37, C46, C48, C52
10u 35V NON POLAR ELECTROLYTIC
CAPACITOR
4 C13, C18, C39, C47
100u 16V NON POLAR ELECTROLYTIC
CAPACITOR
2 C17, C41
1u 16V ELECTROLYTIC CAPACITOR 1 C1
47u 16V ELECTROLYTIC CAPACITOR 1 C59
47u 50V ELECTROLYTIC CAPACITOR 2 C22, C42
100u 16V ELECTROLYTIC CAPACITOR 2 C60, C61
100u 35V ELECTROLYTIC CAPACITOR 1 C54
220u 16V ELECTROLYTIC CAPACITOR 4 C70, C71, C74, C75
220u 50V ELECTROLYTIC CAPACITOR 8 C7, C11, C33, C43, C45,
C64, C65, C66
470u 35V ELECTROLYTIC CAPACITOR 1 C53
2200u 50V ELECTROLYTIC CAPACITOR 8 C21, C23, C25, C26, C29,
C30, C62, C63
PD077 NE5534 SINGLE OP AMP 2 U1, U6
PY010 SAP15NO POWER TRANSISTOR 2 U3, U5
PY016 SAP15PO POWER TRANSISTOR 2 U2, U4
PY539 LM393 DUAL COMPARATOR 1 U7
7805 5V REGULATOR 1 U8
7815 15V REGULATOR 1 U9
7915 -15V REGULATOR 1 U10
PY219 BC327 PNP TRANSISTOR 2 Q1, Q2
PY214 BC337 NPN TRANSISTOR 4 Q3, Q4, Q5, Q6
PY021 MPAS92/93 PNP TRANSISTOR 9 Q7, Q8, Q15, Q16, Q21,
Q28, Q29, Q30, Q33
PY013 MPAS42/43 NPN TRANSISTOR 10 Q9, Q10, Q18, Q19, Q22,
Q26, Q27, Q32, Q35,
Q36
PY012 MJE340 NPN TRANSISTOR 5 Q11, Q12, Q20, Q24,
Q25
PY018 MJE350 PNP TRANSISTOR 2 Q14, Q31
PY536 MPSA13 DARLINGTON NPN TRANSISTOR 2 Q13, Q23
1N4004 RECTIFIER DIODE 10 D2, D4, D8, D10, D13,
D14, D15, D16, D31, D32
1N5402 RECTIFIER DIODE 4 D17, D18, D19, D20 MUST BE RAISED OFF PCB DUE TO
HEAT
1N4148 SIGNAL DIODE 10 D6, D12, D21, D22, D23,
D24, D25, D26, D27, D28
3V3 400mW ZENER DIODE 2 D1, D9
4V7 400mW ZENER DIODE 1 D7
10V 400mW ZENER DIODE 2 D29, D30
2 WAY JST CONNECTOR 2.54mm PITCH 3 CN2, CN4, CN11
3 WAY JST CONNECTOR 2.54mm PITCH 2 CN6, CN8
4 WAY JST CONNECTOR 2.54mm PITCH 1 CN5
8 WAY JST CONNECTOR 2.54mm PITCH 1 CN7
24
