AP PART No. DRAWING NO DESCRIPTION QTY COMMENTS
AP13453/2 A600 INPUT PCB TO FRONT PANEL SWITCH PCB 1 ATTACH FRONT PANEL PCB TO INPUT PCB AS
PER DRAWING
CABLE TIE 2.5mm X 100mm 2 ATTACH CABLE LOOM TO SUB PANEL
AP13391/2 A600 VOLUME MOTOR CABLE 1 ATTACH VOLUME POT MOTOR TO FRONT
PANEL SWITCH PCB
AP13394/2 A600 AMP PCB TO FRONT PANEL CONTROL PCB
CABLE
1 ATTACH FRONT PANEL PCB TO AMP PCB AS PER
DRAWING
BOTTOM PANEL ASSEMBLY
AP12734/1 CAMBRIDGE NEW RANGE AMP BOTTOM PANEL 1
PY541 AP12652/2 CAMBRIDGE NEW RANGE FOOT MOULDING 4 POSITION IN PLACE ON BOTTOM PANEL
PY544 AP12883/3 CAMBRIDGE NEW RANGE FOOT PAD 4 AFFIX ON FOOT USING ADHESIVE SURFACE
M3 X 6 PLASTITE POZI PAN 4 AFFIX FEET TO BOTTOM PANEL
12.7mm PLASTIC PCB STANDOFF 9 PUSH SNAP FIT ON BOTTOM PANEL
M3 X 6 POZI PAN TAPTITE SCREW 12 TO AFFIX SUPPORT BRACKETS (POWER AMP
ASSEMBLY) TO BOTTOM PANEL
M4 X 12 POZI PAN MACHINE BOLT 2 FIX THROUGH EARTHING POINT HOLES ON
BOTTOM PANEL
M4 NUT STANDARD 2 USED TO FIX ABOVE BOLTS
M4 LOCK WASHER 2 FOR EARTH BOLTS
M6 X 60 POZI PAN MACHINE BOLT 1 USED TO FIX MAIN TRANSFORMER IN PLACE
THROUGH THE BOTTOM PANEL
AP12629/5 230V 194VA TOROID TRANSFORMER 1
NEOPRENE TRANSFORMER INSULATION WASHERS 2 TO FIT EITHER SIDE OF TRANSFORMER
TRANSFORMER METAL BOTTOM PLATE 1 TO FIT UNDER BOTTOM PLATE ON M6 BOLT
M6 LOCK WASHER 1 PLACE ABOVE TRANSFORMER ON M6 BOLT
TRANSFORMER METAL TOP PLATE 1 PLACE ON TOP OF TRANSFORMER
M6 NUT STANDARD 1 USED TO FIX ABOVE BOLT
INPUT PCB ASSEMBLY 1 FIXES IN THE CORRECT POSITION ONTO THE
PLASTIC PCB STANDOFFS
AP12715/4 BARE INPUT PCB 1
M2.6 X 6 POZI PAN MACHINE SCREW 10 TO AFFIX BOTTOM PANEL TO SIDE, FRONT AND
REAR PANELS
M2.6 X 10 POZI PAN PLASTITE 4 FIX CORNERS OF BOTTOM PANEL TO PLASTIC
INSERTS
SIDE PANEL ASSEMBLY 2
AP12726/1 CAMBRIDGE AUDIO NEW RANGE PRESSED SIDE PANEL
(3 RIDGE)
2 POSITION IN PLACE ON PLASTIC FRONT INSERTS
AP12729/1 CAMBRIDGE AUDIO NEW RANGE FRONT PLASTIC
SUPPORT (3 RIDGE)
2 POSITION AT FRONT WITHIN SIDE PANELS
AP12730/1 CAMBRIDGE AUDIO NEW RANGE REAR PLASTIC
SUPPORT (3 RIDGE)
2 POSITON AT REAR WITHIN SIDE PANELS
M2.6 X 10 C/S POZI PLASTITE 8 TO AFFIX SIDE PANELS TO PLASTIC INSERTS
A600 REAR PANEL ASSEMBLY 1
AP12919/2 CAMBRIDGE AUDIO NEW RANGE AMP REAR PANEL
PRINTED
1 SCREENED WITH ARTWORK AP13665/2 THEN
POSITION ON REAR PLASTIC SUPPORTS
M3 X 10 POZI PAN PLASTITE 4 TO AFFIX REAR PANEL TO REAR PLASTIC INSERTS
M3 X 8 POZI PAN PLASTITE 9 TO FIX SPEAKER TERMINAL PCB AND ALSO FIX
PHONO SOCKETS ON THE INPUT BOARD TO
THE REAR PANEL
M4 X 8 POZI PAN TAPTITE 2 FIXES THE IEC SOCKET MOUNTED ON THE
POWER BOARD TO THE REAR PANEL
M3X12 MACHINE SCREW WITH PLASTIC KNOB AND
EXTERNAL TOOTH ZINC WASHER
1 PHONO GND SCREW ON REAR PANEL
6
