AP Part No. DRAWING
NO
DESCRIPTION QTY DESIGNATOR COMMENTS
AP13438/1 CAMBRIDGE AUDIO NEW RANGE CD DISPLAY SPACER PAD 1 POSITION UNDER THE
BACKLIGHT WITHIN
THE PLASTIC HOLDER
PY562 AP13337/2 CAMBRIDGE AUDIO NEW RANGE CD LCD POSITIVE 1 POSITION ON THE TOP
LEDGE WITHIN THE
PLASTIC HOLDER AND
FEED PINS THROUGH
RELEVENT HOLES ON
THE FRONT PANEL PCB
M3 X 8 POZI PAN PLASTITE 2 TO FIX DISPLAY
ASSEMBLY TO THE
FRONT PANEL PCB
CONTROL/FRONT PANEL PCB ASSEMBLY (FRONT PANEL SWITCH
PCB)
1 FIXES ONTO THE R/H
SUB PANEL WITH M3
M/C SCREWS
M3 X 6 POZI PAN MACHINE SCREW 11 USED FOR FIXING THE
FRONT PANEL PCB'S
TO THE SUBPLATE
STANDOFF'S
AP13620/1 8 WAY LCD CABLE, FLAT WIRE STYLE 280mm 2 CONNECTS THE
FRONT PANEL PCB TO
THE SERVO PCB, RUNS
AROUND THE SIDE OF
THE CASEWORK
AP13621/1 7 WAY LCD CABLE, FLAT WIRE STYLE 500mm 1 CONNECTS THE
FRONT PANEL PCB TO
THE SERVO PCB, RUNS
AROUND THE SIDE OF
THE CASEWORK
AP13622/1 7 WAY CRONTROL CABLE 520mm 1 CONNECTS THE
FRONT PANEL PCB TO
THE SERVO PCB, RUNS
UNDER THE CD MECH
THEN AROUND THE
OUTSIDE OF THE
CASEWORK
AP13623/1 3 WAY STANDBY CABLE 380mm 1 CONNECTS THE
FRONT PANEL PCB TO
THE STAND BY PCB,
RUNS UNDERNEATH
THE CD MECH
AP13624/1 2 WAY BACKLIGHT POWER CABLE 440mm 1 CONNECTS THE
FRONT PANEL PCB TO
THE SERVO PCB, RUNS
UNDER THE CD MECH
THEN AROUND THE
OUTSIDE OF THE
CASEWORK
AP13894/1 3 WAYDAC AC POWER CABLE 420mm 1 FROM POWER PCB
UNDER DAC PCB TO
DAC PCB
Note, resistors, capacitors and other 'generic' electronic components are not usually stocked by the manufacturer. Please obtain these locally. 13
