AP13752/3
AP Part No. DRAWING NO DESCRIPTION QTY DESIGNATOR COMMENTS
AP12928/6 SERVO PCB ASSEMBLY 1 Blue with white ident
10R 0.125W METAL FILM RESISTOR 1 R62
10R 0.25W METAL FILM RESISTOR 1 R40
27R 1W CARBON RESISTOR 1 R67
47R 0.125W METAL FILM RESISTOR 1 R10
100R 0.125W METAL FILM RESISTOR 1 R58
220R 0.125W METAL FILM RESISTOR 1 R4
470R 0.125W METAL FILM RESISTOR 2 R33, R34
1K 0.125W METAL FILM RESISTOR 5 R3,R20,R21,R25,R60
2K2 0.125W METAL FILM RESISTOR 2 R1, R66
3k3 0.125W METAL FILM RESISTOR 7 R19, R41, R42, R43, R45, R46,
R47
4K7 0.125W METAL FILM RESISTOR 1 R32, R76
5K1 0.125W METAL FILM RESISTOR 4 R53, R54, R55, R56
10K 0.125W METAL FILM RESISTOR 21 R8, R11, R12, R13, R14, R15,
R16, R17, R18, R23, R24, R26,
R27, R28, R29, R30, R31, R39,
R44, R64, R65
15K 0.125W METAL FILM RESISTOR 2 R2, R5
33K 0.125W METAL FILM RESISTOR 2 R52, R57
47K 0.125W METAL FILM RESISTOR 6 R9, R48, R49, R50, R51, R61
68K 0.125W METAL FILM RESISTOR 1 R7
82K 0.125W METAL FILM RESISTOR 1 R59
100K 0.125W METAL FILM RESISTOR 1 R63
220K 0.125W METAL FILM RESISTOR 1 R6
5p CERAMIC COG 50/100V 5mm PITCH CAPACITOR 1 C1
15p CERAMIC COG 50/100V 5mm PITCH CAPACITOR 2 C16, C17
25p CERAMIC COG 50/100V 5mm PITCH CAPACITOR 2 C80, C81
47p CERAMIC COG 50/100V 5mm PITCH CAPACITOR 1 C76
56p CERAMIC COG 50/100V 5mm PITCH CAPACITOR 1 C73
470p CERAMIC 50/100V 5mm PITCH CAPACITOR 2 C24, C25
1n0 CERAMIC 50/100V 5mm PITCH CAPACITOR 1 C87
2n7 MYLAR 5mm PITCH CAPACITOR 1 C6
4n7 MYLAR 5mm PITCH CAPACITOR 2 C7,C21
10n CERAMIC 50/100V 5mm PITCH CAPACITOR 1 C75
15n CERAMIC 50/100V 5mm PITCH CAPACITOR 1 C8
47n CERAMIC 50/100V 5mm PITCH CAPACITOR 11 C5, C11, C13, C15, C19, C22,
C23, C26, C27, C60, C66
100n CERAMIC 50/100V 5mm PITCH CAPACITOR 21 C2, C4, C44, C45, C48, C49,
C51, C52, C53, C54, C57, C58,
C59, C61, C62, C64, C67, C68,
C71, C79, C86
220n CERAMIC 50/100V 5mm PITCH CAPACITOR 2 C3, C72
1u 16V ELECTROLYTIC CAPACITOR 1 C12
Cambridge Azur 640C CD Player (Servo BOM)
