AP Part No. DRAWING NO DESCRIPTION QTY DESIGNATOR COMMENTS
10u 16V ELECTROLYTIC CAPACITOR 2 C69, C82
22u 16V ELECTROLYTIC CAPACITOR 1 C14
47u 16V ELECTROLYTIC CAPACITOR 11 C9, C10, C18, C20, C28, C29,
C65, C70, C74, C77, C78
100u 16V ELECTROLYTIC CAPACITOR 1 C85
220u 16V ELECTROLYTIC CAPACITOR 2 C56, C84
470u 16V ELECTROLYTIC CAPACITOR 3 C46, C47, C83
3300u 25V ELECTROLYTIC CAPACITOR 1 C50
CRYSTAL 16.9344MHz 2 PIN 5mm PITCH 1 X1
PY561 CRYSTAL 7.3728MHz 2 PIN 5mm PITCH 1 X2
PY474 TA2153FN (TOSHIBA RF Amplifier) 1 U1
PY475 TC9462F (TOSHIBA Digital Servo-chip Processor) 1 U2
PY565
I.C. MCU TMP87EP26F-1J15 SOP TOSHIBA
1U3
PY473 TA2092N (TOSHIBA Power driver IC) 1 U6
7808 (TO-220 +8V Regulator) 1 U7
7805 (TO-220 +5V Regulator) 1 U8
PY560 9015 1 Q1
PY014 8050 (TRANSISTOR NPN C8050) 4 Q7, Q8, Q11, Q12
PY559 8550 (TRANSISTOR PNP C8550) 2 Q9, Q10
PY558 9014C (TRANSISTOR NPN 9014C) 1 Q13
DIODE 1N4148 2 D8, D9, D10, D11
DIODE ,IN4004 3 D2, D3, D4, D5
2 Way, 2mm Pitch JST Type connector (XIN X1, UNREG
OUT X1, MUTE X1)
3 CN17, CN20, CN21
3 Way, 2mm Pitch JST Type connector (DIGITAL OUT
X1)
1 CN1
5 Way, 2mm Pitch JST Type connector (DATA OUT X1,
Draw drive X1) .
2 CN2, CN8
6 Way, 2mm Pitch JST Type connector (MOTOR DRIVE) 1 CN15
7 Way, 2mm Pitch JST Type connector (LCD X1, F/P
CONTROLS)
2 CN6, CN7
8 Way, 2mm Pitch JST Type connector
(PROGRAMMING X1, LCD X2)
3 CN3, CN4, CN5
2 Way, 2.5mm 2mm Pitch JST Type connector (AC IN) 1 CN19
CONNECTOR FFC 16-WAY 1.0mm PITCH (MECH) 1 CN16
FUSE HOLDER 20mm 1 FU1
2A 1 FU1
47uH (8mm pitch) 1 L1
100uH (8mm pitch) 4 L2, L3, L4, L5
HEATSINK FOR U7 & U8 2 (U7, U8)
M3 X 6 TAPTITE POZI PAN MACHINE SCREW 4 TO FIT HEATSINK TO PCB
(X2) TO FIT U7 & U8 TO
HEATSINK (X2)
