Cambridge Audio 640C - Main Assembly BOM (Silver Unit)

AP13752/3
AP Part No. DRAWING
NO
DESCRIPTION QTY COMMENTS
AP13504/1 POLY ENDCAP PACKAGING 2
AP13505/1 CARTON PACKAGING W/HANDLE 1 PRINTED TO ARTWORK AP13716/1
AP13613/1 CAMBRIDGE AUDIO AZUR WOVEN BAG FOR REMOTE CONTROL 1 PACK REMOTE CONTROL INSIDE,
CAMBRIDGE AZUR REMOTE CONTROL COMPLETE. MODEL No RC-
540AC/640AC
1 MOUNTED INTO POLY ENDCAP
PACKING IN REBATE PROVIDED
AAA ALKALINE BATTERIES 3 FOR REMOTE. PLACE IN
INSTRUCTION MANUAL POLYBAG
PY566 AP14004/1 640C CD PLAYER OWNERS' MANUAL 1
AP13945/1 CARTON LABEL (MODEL NO.) UK SILVER 1 FOR BOX
SERIAL NUMBER LABEL, BLANK (6.5X35.5mm) 3 1 X REAR PANEL, 1 X BOX, 1 X
SHIPPING CARTON
ISO 9002 LABEL 1 AFFIXED TO REAR PANEL ABOVE
IEC SOCKET
AP10087/2 "MADE UNDER LICENCE IN PRC" STICKER 1 AFFIXED TO REAR PANEL BELOW
IEC SOCKET
POLYBAG 173X260X4C mm 1 FOR INSTRUCTION
MANUALOWNERS CERTIFICATE
AND REMOTE BATTERIES
AP13612/1 CAMBRIDGE AUDIO AZUR 2 RIDGE WOVEN BAG 1 PACK AMP UNIT INSIDE
1830mm AC IEC POWER CORD SET BS STANDARD FUSED 3 AMP 1 MUST BE BS APPROVED
BLUE TAPE SEAL FOR CAMBRIDGE CARTON 1
FRONT PANEL ASSEMBLY
PY586 AP12741/1 CAMBRIDGE NEW RANGE CD FRONT PANEL (PUNCHED AND PRINTED)
(SILVER)
1 SCREENED WITH ARTWORK
AP13591/3 & AP13593/1
AP12935/1 CAMBRIDGE NEW RANGE IR LENS 1 GLUED IN PLACE ON THE FRONT
PANEL
AP13322/1 CAMBRIDGE NEW RANGE 105mm DISPLAY WINDOW 1 GLUED IN PLACE ON THE FRONT
PANEL
AP13436/2 CAMBRIDGE NEW RANGE CD SUB PANEL LEFT (POWER) 1 FASTENEND IN PLACE INBETWEEN
THE LEDGES ON THE FRONT
PANEL, ALIGN UP THE POWER
BUTTON HOLES
AP12931/1 CAMBRIDGE NEW RANGE AMP LIGHTGUIDE, CUT TO SINGLE PIPE 1 FASTEN TO SUBPLATE LEFT
(POWER)
M3 X 6 POZI PAN STP SCREW 1 AFFIXES SINGLE LIGHTGUIDE TO
SUBPLATE
M3 X 6 C/S POZI MACHINE SCREW 4 FASTEN THE SUB PLATE LEFT TO
THE FRONT PANEL
AP13585/1 CAMBRIDGE NEW RANGE AMP 9mm TAC SWITCH CUSHION 1 POSITION ON THE CONTROL BOX
BUTTON, DOWN THE MAIN SHAFT
AFFIX USING ADHESIVE PROVIDED
ON THE CUSHION.
PY145 AP11782/1 OPUS CONTROL BOX BUTTON (SILVER) 1 POSITION IN PLACE ON THE
FRONTPANEL
AP13437/2 CAMBRIDGE NEW RANGE CD SUB PANEL RIGHT (FUNCTION) 1 FASTENEND IN PLACE INBETWEEN
THE LEDGES ON THE FRONT
PANEL, ALIGN UP THE FUNCTION
BUTTON HOLES
M3 X 6 C/S POZI MACHINE SCREW 4 FASTEN THE SUB PLATE RIGHT TO
THE FRONT PANEL
AP12934/1 CAMBRIDGE NEW RANGE AMP 7mm TAC SWITCH CUSHION 5 POSITION ON THE 7mm TACT
SWITCH BUTTONS, DOWN THE
MAIN SHAFT AFFIX USING
ADHESIVE PROVIDED ON THE
CUSHION.
AP12925/1 CAMBRIDGE NEW RANGE AMP 7mm TAC SWITCH BUTTON 5 POSITION IN PLACE ON THE
FRONTPANEL
Cambridge Azur 640CCD Player (Main Assembly BOM Silver Unit)
Note, resistors, capacitors and other 'generic' electronic components are not usually stocked by the manufacturer. Please obtain these locally. 6
