Cambridge Audio 640C - Page 7

AP Part No. DRAWING
NO
DESCRIPTION QTY COMMENTS
BOTTOM PANEL ASSEMBLY
AP12735/5 CAMBRIDGE NEW RANGE CD BOTTOM PANEL 1
12.2mm BRASS THREADED STANDOFF 1 POSITION IN PLACE ON BOTTOM
PANEL
M3 X 8 POZI PAN MACHINE SCREW 1 TO AFFIX BRASS THREADED
STANDOFF TO BOTTOM PANEL
PY541 AP12652/2 CAMBRIDGE NEW RANGE FOOT MOULDING (SILVER) 4 POSITION IN PLACE ON BOTTOM
PANEL
PY544 AP12883/3 CAMBRIDGE NEW RANGE FOOT PAD 4 AFFIX ON FOOT USING ADHESIVE
SURFACE
M3 X 6 PLASTITE POZI PAN 4 AFFIX FEET TO BOTTOM PANEL
12.7mm PLASTIC PCB STANDOFF 7 PUSH SNAP FIT ON BOTTOM PANEL
8 mm PLASTIC PCB STANDOFF 1 PUSH SNAP FIT ON BOTTOM PANEL
M4 X 12 POZI PAN MACHINE BOLT 2 FIX THROUGH EARTHING POINT
HOLES ON BOTTOM PANEL
M4 NUT STANDARD 2 USED TO FIX ABOVE BOLTS
M4 LOCK WASHER 2 FOR EARTH BOLTS
M4 X 12 POZI PAN MACHINE BOLT 2 TO FIX THROUGH TRANSFORMER
HOLES IN BOTTOM PANEL
M4 LOCK WASHER 2 PLACE ON TRANSFORMER FIXING
BOLTS
M4 NUT STANDARD 2 USED TO FIX TRANSFORMER IN
PLACE
FW-2S PIN GOOD STICK ON CABLE CLIP 3 USED TO CLIP DAC POWER CABLE
AP13894/ AND TRANSFORMER TO
SERVO BOARD CABLE
AP13571/1 CAMBRIDGE AUDIO NEW RANGE CD TRANSFORMER PAD 1 POSITION IN PLACE ON BOTTOM
PANEL WITH THE FIXING BOLTS
THROUGH SUPPLIED HOLES
PY563 AP13157/3 CAMBRIDGE AUDIO EI 115/230V 540C/640C TRANSFORMER 1 POSITION ON TRANSFORMER PAD
WITH FIXING BOLTS THROUGH
SUPPLIED HOLES
AP13545/1 CAMBRIDGE AUDIO NEW RANGE CD TRANSFORMER CAN WITH ADHESIVE
PAD ADDED
1 SCREENED WITH ARTWORK
AP13721/1 POSITION ON TOP OF
TRANSFORMER AND PRESS TO
STICK IN PLACE
CD Mechanism with Loader 1 POSITION IN THE CORRECT
POSITION ON THE BOTTOM PANEL
PY057 CD mechanism (Sony) 1
M3 X 6 POZI PAN MACHINE SCREW 4 TO AFFIX THE CD MECH TO THE
BOTTOM PANEL
AP13895/1 MAINS PCB INSULATING SHEET 1 TO BE POSITIONED OVER
STANDOFFS UNDER POWER PCB
AP13544/2 CAMBRIDGE AUDIO NEW RANGE CD MECH TOP STICKER 1 SCREENED WITH ARTWORK
AP13763/1THEN POSITION OVER
LOCATING PIPS ON CD MECH TOP
SURFACE AND PRESS TO STICK
PY568 AP13495/1 CAMBRIDGE AUDIO NEW RANGE CD DRAW FRONT (SILVER) 1 SCREENED WITH ARTWORK
AP13601/1 POSITON ON DRAW
FRONT AND GLUE IN PLACE
M3x8 POSIPAN MACHINE SCREW 1 TO FIX SERVO BOARD TO BRASS
THREADED STAND OFF
AP13617/1 16 WAY LASER CABLE, FLEXIBLE FLAT CABLE 250mm 1 CONNECTS SERVO PCB TO LASER
BLOCK ON THE CD MECH
Note, resistors, capacitors and other 'generic' electronic components are not usually stocked by the manufacturer. Please obtain these locally. 7
