AP13752/3
AP Part No. DRAWING NO DESCRIPTION QTY DESIGNATOR COMMENTS
AP13638/2 MAINS PCB ASSEMBLY 1 BLUE WITH WHITE
SILK SCREEN
10n CERAMIC X1 Y2 MAINS RATED CAPACITOR 2 C1,C2
FUSE T1AL 1 FU3
FUSE F1AL 2 FU1,FU2
PY091 Fuse holder 3 FU1,FU2,FU3
PY092 Fuse cover 3 FU1,FU2,FU3
EYELET 2.3x4mm 3 J1,J2,J3
LINK WIRE 24SWG 10mm LONG 2 LK1, LK2 FITTED TO LK1 OR
LK2
AP13903/1 160mm GREEN/YELLOW GROUNDING WIRE WITH 1
RING M4 AWG#18
1 IEC CONNECTOR
EARTH TAG TO
GROUND ON
CHASSIS
3 way 2.5mm pitch JST type connector 2 CN1, CN2
IEC MAINS SOCKET PC1287 1 CN3 FIRST TECH AS PER
D500 SE CD PLAYER
2 BOLT M3x10 BLACK 1 IEC CONNECTOR
TO PCB
2 LOCK WASHER M3 1 IEC CONNECTOR
TO PCB
2 NUT M3 HEX M3X5.5X2.4mm 1 IEC CONNECTOR
TO PCB
