Cambridge Audio 640C - Front Panel BOM (Silver Unit)

AP13752/3
AP Part No. DRAWING
NO
DESCRIPTION QTY DESIGNATOR COMMENTS
AP12993/3 CONTROL/FRONT PANEL PCB ASSEMBLY (FRONT PANEL SWITCH
PCB) SNAP OFF
1 BLUE WITH WHITE
IDENT
33R 0.25W 1% METAL FILM RESISTOR 1 R16
330R 0.25W 1% METAL FILM RESISTOR 1 R15
820R 0.25W 1% METAL FILM RESISTOR 1 R1
1K5 0.25W 1% METAL FILM RESISTOR 1 R8
1K8 0.25W 1% METAL FILM RESISTOR 1 R2
2K7 0.25W 1% METAL FILM RESISTOR 1 R5
3K3 0.25W 1% METAL FILM RESISTOR 1 R11
10K 0.25W 1% METAL FILM RESISTOR 2 R6,R13
4K7 0.25W 1% METAL FILM RESISTOR 1 R12
27K 0.25W 1% METAL FILM RESISTOR 1 R3
33K 0.25W 1% METAL FILM RESISTOR 1 R4
68K 0.25W 1% METAL FILM RESISTOR 1 R10
82K 0.25W 1% METAL FILM RESISTOR 2 R7,R9
1000p CERAMIC 50/100V 5mm PITCH CAPACITOR 2 C2,C3
100n CERAMIC 50/100V 5mm PITCH CAPACITOR 1 C1,C4
10uF 10V ELECTROLYTIC CAPACITOR 2.5mm PITCH 1 C6
PY054 TSOP18 IR RECEIVER 1 U2
PY605 16C505 (MICROCHIP) 1 U3 PROGRAMED WITH
AP13762/1
PY214 BC337 1 Q1
PY219 BC327 1 Q2
1N4148 2 D1,D3
TACTILE SWITCH 5 SW1,SW2, SW3,
SW4,SW5
AS PER D500SE
2way JST type connector 90deg 2mm 1 CN1
8way JST type connector 90deg 2mm 2 CN2,CN3
7way JST type connector 90deg 2mm 2 CN4,CN7
3way JST type connector 90deg 2mm 1 CN5
AP13344/1 CAMBRIDGE AUDIO NEW RANGE BACKLIGHT AND LCD PLASTIC
HOLDER
1 LCD1
CONTROL PCB ASSEMBLY (FRONT PANEL SWITCH PCB) FIXES ONTO THE L/H
SUB PANEL WITH M3
M/C SCREWS
AP12993/3 CONTROL/FRONT PANEL PCB ASSEMBLY (POWER SWITCH) SNAP
OFF
BLUE WITH WHITE
IDENT
820R 0.25W 1% METAL FILM RESISTOR 1 R14
PY064 FLAT TOP BLUE LED 1 D2
TACTILE SWITCH 1 SW6 AS PER D500SE
3way JST type connector 90deg 2mm 1 CN6
DISPLAY ASSEMBLY
AP13344/1 CAMBRIDGE AUDIO NEW RANGE BACKLIGHT AND LCD PLASTIC
HOLDER
1 USE AS DISPLAY
ASSEMBLY REFERENCE
YANION BACKLIGHT PCB WITH TWO WHITE LEDS (JAPANESE) 1 POSITION WITHIN THE
BACKLIGHT
AP13343/2 CAMBRIDGE AUDIO NEW RANGE BACKLIGHT WITH SILVER STRIPS 1 POSITION IN PLACE
WITHIN THE
UNDERSIDE OF THE
PLASTIC HOLDER
AP14277/1 Backlight Correction Sheet Mechanical Details 1 Artwork AP14278/1
Cambridge Azur 640C CD Player (Front Panel BOM Silver Unit)
Note, resistors, capacitors and other 'generic' electronic components are not usually stocked by the manufacturer. Please obtain these locally. 12
