Cambridge Audio 640C - Page 8

AP Part No. DRAWING
NO
DESCRIPTION QTY COMMENTS
AP13618/1 5 WAY TRAY MOTOR CABLE FLAT WIRE STYLE 350mm 1 CONNECTS THE SERVO PCB TO
THE CD MECH, RUNS UNDER THE
FRONT OF THE MECH AND UNDER
THE SERVO PCB
AP13619/1 6 WAY SPINDLE MOTOR CABLE 200mm 1 CONNECTS THE SERVO PCB TO
THE CD MECH, RUNS UNDER THE
CD MECH
AP10616/6 SERVO PCB SHIELDING CAN 1 SCREENED WITH ARTWORK
AP13721/1 POSITION OVER SEVRO
PCB AND SOLDER FIX
AP10001/2 CAMBRIDGE AUDIO SCREENING CAN 1 POSITION OVER DAC PCB AND
SOLDER FIX
AP13625/1 2 WAY MUTE CABLE, FLAT WIRE STYLE CABLE 300mm 1 CONNECTS DAC PCB TO THE
SERVO PCB
AP13626/1 3 WAY SHIELDED DIGITAL OUT CABLE 130mm 1 CONNECTS DAC PCB TO THE
SERVO PCB
AP13627/1 5 WAY SHIELDED DIGITAL OUT CABLE 120mm CONNECTS DAC PCB TO THE
SERVO PCB
AP13628/1 2 WAY SHIELDED MASTER CLOCK CABLE 160mm 1 CONNECTS DAC PCB TO THE
SERVO PCB
M2.6 X 6 POZI PAN MACHINE SCREW 5 TO AFFIX BOTTOM PANEL TO SIDE,
FRONT AND REAR PANELS
M2.6 X 10 POZI PAN PLASTITE 4 FIX CORNERS OF BOTTOM PANEL
TO PLASTIC INSERTS
SIDE PANEL ASSEMBLY 2
AP12725/1 CAMBRIDGE AUDIO NEW RANGE PRESSED SIDE PANEL (2 RIDGE) (SILVER) 2 POSITION IN PLACE ON PLASTIC
FRONT INSERTS
AP12727/1 CAMBRIDGE AUDIO NEW RANGE FRONT PLASTIC SUPPORT (2 RIDGE WITH
CAPTIVE M2.6 NUTS)
2 POSITION AT FRONT WITHIN SIDE
PANELS
AP12728/1 CAMBRIDGE AUDIO NEW RANGE REAR PLASTIC SUPPORT (2 RIDGE WITH
CAPTIVE M2.6 NUTS)
2 POSITON AT REAR WITHIN SIDE
PANELS
M2.6 X 10 C/S POZI PLASTITE 8 TO AFFIX SIDE PANELS TO PLASTIC
INSERTS
D640C REAR PANEL ASSEMBLY 1
AP13435/2 CAMBRIDGE AUDIO NEW RANGE CD REAR PANEL PRINTED 1 SCREENED WITH ARTWORK
AP13669/1, THEN POSITION ON
REAR PLASTIC SUPPORTS
M3 X 10 POZI PAN PLASTITE 4 TO AFFIX REAR PANEL TO REAR
PLASTIC INSERTS
M3 X 8 POZI PAN PLASTITE 3 TO FIX DAC PCB ELECTRONIC
PARTS TO REAR PANEL
M3 X 10 POZI PAN MACHINE SCREW 2 FIXES THE IEC SOCKET MOUNTED
ON THE POWER BOARD TO THE
REAR PANEL
M3 NUT STANDARD 2 USED TO FIX ABOVE BOLTS
M3 LOCK WASHER 2 USED TO FIX ABOVE BOLTS
AP13340/1 A600 LIDDING TAPE FOR FRONT AND REAR PANELS 2 FIX TO THE CORRECT SURFACES
FOR LID
AP13342/1 A600 LIDDING TAPE FOR SIDE PANELS 2 FIX TO THE CORRECT SURFACES
FOR LID
PY574 AP12733/2 CAMBRIDGE AUDIO NEW RANGE TOP PANEL WITHOUT VENTS (SILVER) 1 POSITIONON TOP OF THE
PRODUCT
PY516 M2.6 X 6 C/S TORX MACHINE SCREW (SILVER) 8 TO AFFIX TOP PANEL TO PLASTIC
INSERTS, SIDE, REAR AND FRONT
PANEL
Note, resistors, capacitors and other 'generic' electronic components are not usually stocked by the manufacturer. Please obtain these locally. 8
