Cambridge Audio 840A - Page 49

74HC4094
Front Panel PCB - (U2, U3, U4, U5 & U6)
BC327
Front Panel PCB - (Q1 & Q8)
A-BUS PCB – (Q1)
LM393AP
Right Hand Power Amp PCB - (U1)
Left Hand Power Amp PCB – (U1)
MJE340
Right Hand Power Amp PCB - (Q1, Q12 &
Q18)
Left Hand Power Amp PCB – (Q1, Q12, Q18 &
Q30)
MJE350
Right Hand Power Amp PCB - (Q2)
Left Hand Power Amp PCB – (Q2)
MPSA93
Right Hand Power Amp PCB - (Q3, Q4, Q5 Q6,
Q20, Q22, Q24, Q27, Q28 & Q29)
Left Hand Power Amp PCB – (Q3, Q4, Q5, Q6,
Q20, Q22, Q24, Q27, Q28, Q29, Q31)
MPSA43
Right Hand Power Amp PCB - (Q7, Q8, Q9,
Q10, Q19, Q21, Q23, Q25 & Q26)
Left Hand Power Amp PCB – (Q7, Q8, Q9,
Q10, Q19, Q21, Q23, Q25, Q26)
