2SA1295
Right Hand Power Amp PCB - (Q13, Q14 &
Q17)
Left Hand Power Amp PCB – (Q13, Q14 &
Q17)
2SC3264
Right Hand Power Amp PCB - (Q15 & Q16)
Left Hand Power Amp PCB – (Q15 & Q16)
CD4011BE
A-BUS PCB - (U7)
7812
A-BUS PCB - (U2)
OP4N25
A-BUS PCB - (U8)
PIC16F627-04/P
A-BUS PCB - (U5)
TSOP34837
A-BUS PCB - (U4)
TSOP34836
A-BUS PCB - (U6)
50
