Pag. 13 - FA01497M4A - 03/2021 - © CAME S.p.A. -
Description
S0002P - External, two-channel, 12-24 V AC - DC IP54 control card for keypads and transponder.
Description of parts
❶Save code key for channel 1 (OUT1)
❷Save code key for channel 2 (OUT2)
❸Delete all code key
❹Warning LED
❺Expansion board
❻Terminals for channel outputs OUT1 and OUT2
❼Power supply terminals
❽Terminals for connecting accessories
Size
Installation
Fix the board container in a place protected from knocks.
The distance between the S0002P card and the keypad selector or transponder must be
max. 30 m.
Connections
Connect up the electrics as shown in the figure.
Connect up to 4 keypad selectors or 4 transponder selectors.
Use H05RN-F cables that are 60245 IEC 57 (IEC) compliant.
Incoming current protection / limitation of 500 mA is recommended.
Technical data
Type 806SL-0370
Power supply (V AC/DC)
12 - 24
Protection rating (IP)
54
Maximum power draw at 24V AC (mA)
350
Number of relay contacts
2*
24V DC max relay capacity (A)
1
Max. users
250**
Operating temperature (°C)
-20 to +55
Device class
III
* OUT1 = Monostable, OUT2 = configurable as Monostable (default) / Bistable / Hold-to-run.
** With the expansion board inserted.
