CAME G4040E User Manual

L N L1T L2T M N FC FA F + E -
10 11 E1 E6
+
-
26V
0V
230
0
24V 0
THERMAL
L N L1T L2T
p.
13
13 - Manual code:
FA0 0132
- E N
-EN v.
2
2 08/2016
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without notice.
Power supply
Terminals for powering up accessories:
- a 24 V AC normally;
- a 24 V DC when the emergency batteries
are operating;
Overall allowed power: 40 W
Transformer
Red
White
Blue
Orange
24 V DC gearmotor with encoder
The gearmotor is already connected.
To install the barrier on the right, follow the instructions in the PREPARING THE BARRIER section.
Factory wiring
White
Brown
Green
Brown
Blue
Eyelet with screw and washer for
ground connection
230 V AC, 50/60 Hz
