0.1 01/2009 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
5 Installation
Make sure all tools and materials necessary are within reach to install the edge in total safety, and in compliance with the regulations
in force. The following figure illustrates the minimum equipment needed by the installer.
Before proceeding with the installation, it is necessary to:
• Make sure the area selected for the mounting of the base and for the unit itself is hazard free;
• Provide for a suitable omnipolar disconnection device with contacts more than 3 mm apart, and independent (sectioned off) power
supply;
• Make sure that any connections inside the case (that provide continuance to the protective circuit) be fitted with extra insulation as
compared to the other conductive parts inside;
• Make sure that the point where the gearmotor is fastened is protected from impact and that it is sturdy. The fastening must be carried
out using screws and/or rivets that are suitable for the type of surface;
• Make sure that any connections inside the container (made for the continuity of the protection system) are provided with additional
insulation compared to the other conductive parts inside;
• Make sure that the door has a sturdy enough structure, that the hinges be in proper working order and that there is friction between
moving and fixed parts;
The installation must be carried out by export, qualified personnel in total compliance with the norms in effect.
5.1 Preliminary checks
5.2 Tools and materials
4.4 Dimensions
