Cameron Barton 199 - Page 31

3
0
Figure 6-1. 199 DPU Dimension Drawing (Part 2 of 2)
Table 6-1. 199 DPU Dimensions
PRESSURE
PRESSURE
RATING
PSI (MPa)
HOUSING
MATERIAL
CONNECTION
DIM. A
INCHES
(mm)
DIM. B
INCHES
(mm)
DIM. C
INCHES
(mm)
# BOLTS
TOP BOTTOM
1,000
(6.9)
CAST ALUM. 356T6
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
6-5/8
(168.3)
2
(50.8)
2-9/64
(54.4)
6
NACE
2,000
(13.8)
FORGED ST. AISI C1018
(For NACE Service)
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
Ø 7
(177.8)
2
(50.8)
2-9/64
(54.4)
6
2,500
(17.2)
FORGED ST. AISI C1018
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
Ø 7
(177.8)
2
(50.8)
2-9/64
(54.4)
6
3,000
(20.7)
FORGED STNL. ST. 316
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
Ø 7
(177.8)
2
(50.8)
2-9/64
(54.4)
12
4,500
(31.0)
FORGED ALLOY ST. 4142
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
Ø 7
(177.8)
2
(50.8)
2-9/64
(54.4)
12
6,000
(41.4)
FORGED ALLOY ST. 4142
FORGED STNL. ST. 17-4 PH
9/16-18
UNF
(Note 2)
9/16-18
UNF
(Note 2)
Ø 7
(177.8)
2
(50.8)
2
(50.8)
12
FORGED ALLOY ST. 4142
FORGED STNL. ST. 17-4 PH
1/2 NPT
(Note 1)
1/4 NPT
(Note 1)
Ø 7
(177.8)
2
(50.8)
2-9/64
(54.4)
12
Note 1: Can be reversed when ordered or can be rotated 180° in the eld.
Note 2: Suitable for use with Aminko ttings (American Inst. Co., Silver Springs, MD.) or equiv..
Note 3: All Standard pipe ttings furnished by customer.
(Metric conversions are approximate.)
