Cameron BARTON 289A - Page 24

24
ITEM
DESCRIPTION
PART NO.
PER
UNIT
1 DIFFERENTIAL PRESSURE UNIT (NOT SHOWN) SEE DPU 199
MANUAL
1
2 LOW ALARM, EXT. WIRING ASSY., 2.5’ LENGTH (NOT SHOWN): 1
UNITS WITHOUT RELAY, SPDT 0288-0021B
UNITS WITHOUT RELAY, DPDT S401-0018Z
UNITS WITH RELAY, SPDT OR DPDT 0288-0008B
3 HIGH ALARM, EXT. WIRING ASSY., 2.5’ LENGTH (NOT SHOWN): 1
UNITS WITHOUT RELAY. SPDT S655-0056B
UNITS WITHOUT RELAY, DPDT S401-0093Z
UNITS WITH RELAY, SPDT OR DPDT 0288-0007B
4 LOW ALARM, SWITCH ASSY.: 1
UNITS WITHOUT RELAY. SPDT 0288-0024B
UNITS WITHOUT RELAY, DPDT S401-0053Z
UNITS WITH RELAY, SPDT OR DPDT 0288-0039B
5 HIGH ALARM, SWITCH ASSY.: 1
UNITS WITHOUT RELAY, SPDT 0288-0025B
UNITS WITHOUT RELAY, DPDT S401-0056Z
UNITS WITH RELAY, SPDT OR DPDT 0288-0040B
6 NOT USED
7 LOW ALARM DRIVE PLATE ASSY. 0288-0026B 1
8
HIGH ALARM DRIVE PLATE ASSY. 0288-0027B 1
9
LOW SWITCH ADJUSTMENT INDEX ASSY. 0288-0028B 1
10
HIGH SWITCH ADJUSTMENT INDEX ASSY. 0288-0029B 1
11
LOW RELAY ASSY. ( * = Non-CE Use Only): 1
Coil Voltage Wired SPDT
Wired DPDT
6 VAC 0288-0015B
0288-1045B
12 VAC 0288-0045B
0288-1035B
24 VAC 0288-0016B
0288-1044B
*125 VAC 0288-0017B
0288-1043B
*250 VAC 0288-0046B
0288-1034B
6 VDC 0288-0018B
0288-1038B
12 VDC 0288-0019B
0288-1037B
24 VDC 0288-0020B
0288-1036B
*110 VDC 0288-0047B
0288-1033B
12 HIGH RELAY ASSY. ( * = Non-CE Use Only): 1
Coil Voltage Wired SPDT
Wired DPDT
6VAC 0288-0009B
0288-1054B
12 VAC 0288-0042B
0288-1048B
24 VAC 0288-0010B
0288-1053B
*125 VAC 0288-0011B
0288-1052B
*250 VAC 0288-0043B
0288-1047B
6VDC 0288-0012B
0288-1051B
12 VDC 0288-0013B
0288-1050B
24 VDC 0288-0014B
0288-1049B
*110 VDC 0288-0044B
0288-1046B
Table 5-1. Model 289A Parts List
