Cameron BARTON 289A - Page 25

25
ITEM
DESCRIPTION
PART NO.
PER
UNIT
**13 POINTER ASSY.: 1
WHITE 0288-0030B
BLACK 0288-0031B
14 BEZEL ASSY. (WITH PLASTIC LENS) 0277-0018B 1
15 PLATE SCREW:
LOW OR HIGH ALARM (SINGLE) 0317-0012C 1
DUAL ALARM 0317-0012C 2
16 SPRING WASHER:
LOW OR HIGH ALARM (SINGLE) 0257-0019C 1
DUAL ALARM 0257-0019C 2
17 SWITCH PLATE SPACER, HIGH ALARM (SINGLE) 0258-0007C 1
18 LINK PLATE:
LOW OR HIGH ALARM (SINGLE) 0288-0016C 1
DUAL ALARM 0288-0016C 2
19 STRAP:
LOW OR HIGH ALARM (SINGLE) 0288-0017C 1
DUAL ALARM 0288-0017C 2
20 PLUG, SCREW, 4-40 X 1/8. SL., RD., HD. (NOT SHOWN):
LOW OR HIGH ALARM (SINGLE)
DUAL ALARM
0111-0007J 5
0111-0007J 4
LOW OR HIGH ALARM (SINGLE) WITH RELAY 0111-0007J 3
21 SCREW, 4-40 X 1/4 SST SL. ,FL., HD. (WITH RELAY
ONLY):
LOW OR HIGH ALARM (SINGLE) 0112-1022J 2
DUAL ALARM 0112-1022J 4
22 SCREW, 3-48 X 3/16, SST SL., BINDING HD.:
LOW OR HIGH ALARM (SINGLE) 0117-0007J 3
DUAL ALARM 0117-0007J 6
23 SCREW, 8-32 X 1/4, SST, SL., BINDING HD.:
LOW OR HIGH ALARM (SINGLE) 0117-0016J 1
DUAL ALARM 0117-0016J 2
24 PLUG SCR., 8-32 X 1/4, SST, PAN HD. (SINGLE) 0119-0042J 1
(NOT SHOWN)
25 WASHER, SST:
LOW OR HIGH ALARM (SINGLE) 0317-0019J 1
DUAL ALARM 0317-0019J 2
26 WASHER, NO.3 FLAT, SST:
LOW OR HIGH ALARM (SINGLE) 0003-0045K 4
DUAL ALARM 0003-0045K 8
27 GRIP RING (LOW/HIGH ALM.) (SINGLE/DUAL) 0087-0011 T 1
28 WIRE NUT CONNECTOR (NOT SHOWN):
LOW OR HIGH ALARM (SINGLE) WITH RELAY 0109-0017T 1
DUAL ALARM WITH RELAY 0109-0017T 2
29 MOVEMENT ASSEMBLY 0288-0035B 1
30 LINK ASSEMBLY 0288-0036B 1
31 DRIVE ARM ASSEMBLY: 289A (199 DPU) 0288-0037B 1
32 CASE ASSEMBLY 0288-0038B 1
Table 5-1. Model 289A Parts List (cont'd)
