Cameron BARTON 289A - Troubleshooting

26
ITEM
DESCRIPTION
PART NO.
PER
UNIT
32 CASE ASSEMBLY 0288-0038B 1
33 SCREW, RETAINER 0181-0007C 3
34 STOP, SNUBBER 0226-0028C 2
**35 GASKET, BEZEL 0277-0026C 1
36 RISER, MOVEMENT 0277-0035C 2
37 BRACKET, STOP 0288-0028C 1
38 BRACKET, TERMINAL BLOCK 0288-0029C 1
39 SCREW, 6-32 X 3/8, SL., RD., HD. 0111-0015J 2
40 SCREW, 4-40 X 3/16 SST, SL., FIL., HD. 0114-0023J 4
41 SCREW, 4-40 X 3/16, SST., SL, BINDING HD. 0117-0012J 1
42 SCREW, 6-32 X 3/16 SST, SL. BINDING HD. 0117-0013J 4
43 SCREW, 10-32 X 1/2, FL. HD., SOC. 0240-0015J 10
44 SCREW, 1/2-20 X 1, SL. SET SCREW 0340-0003J 4
45 NUT, 1/4-20 HEX 0500-0010J 4
46 STUD, BEZEL, RETAINING, DRIV-LOK 0004-0005K 1
47 BLOCK, TERMINAL 0038-0033T 1
48 PLATE, SCALE (SEE NOTES BELOW): 1
BLACK 0288-0031C
WHITE 0288-1014C
49 ID. TAG (NOT SHOWN) 0199-0125C 1
50 SWITCH, WIRED, LOW ALARM (NOT SHOWN): 1
LOW ALARM, SPDT (WITHOUT RELAY) 0257-0009B
LOW ALARM, DPDT (WITHOUT RELAY) #1 0257-0009B
LOW ALARM, DPDT (WITHOUT RELAY) #2 S401-0016Z
LOW ALARM (WITH RELAY) 0288-0004B
51 SWITCH, WIRED, HIGH ALARM (NOT SHOWN): 1
HIGH ALARM, SPDT (WITHOUT RELAY) 0257-0008B
HIGH ALARM, DPDT (WITHOUT RELAY) #1 0257-0008B
HIGH ALARM, DPDT (WITHOUT RELAY) #2 S401-0017Z
HIGH ALARM (WITH RELAY) 0288-0003B
52 DISC, SEALER, 112” (WITH 3M 468 ADHESIVE) 0192-1035T 1
53 CALIBRATION KIT (NOT SHOWN) 0288-1032B 1
54 INSULATOR STRIP 0038-1345T 1
55 LENS (PLASTIC) 0181-0038C 1
56 PULLER, POINTER (NOT SHOWN) 0163-0005B 1
57 RETAINER RING:
SINGLE ALARM 0087-0015T 1
DUAL ALARM 0087-0015T 2
* INDICATES NON-CE USE ONLY.
** INDICATES RECOMMENDED SPARE PART. WHEN ORDERING PARTS, PLEASE SPECIFY THE SERIAL
NUMBER OF THE INSTRUMENT WITH WHICH THEY ARE TO BE USED.
SCALEPLATE IDENTIFICATION:
IF THE PLATE SHOWS AN SCR NUMBER, THIS WITH IDENTIFY IT. OTHERWISE, PROVIDE THE FOLLOWING-
INFORMATION:
• SQUARE ROOT OR LINEAR GRADUCATION
• SCALE (E.G., 0-100, 25-0-100, ETC.)
• NUMBER OF GRADUATIONS (LINEAR SCALES ONLY)
• DATA (E.G., PSID, INCHES WATER COLUMN, ETC.)
IF THE PLATE HAS MULTIPLE SCALES OR COLORS (OTHER THAN BLACK AND WHITE), CONSULT FACTORY
FOR PRICING/DESCRIPTION.
Table 5-1. Model 289A Parts List (cont'd)
