Cameron BARTON 289A - Table 4.1-Parts List, Model 289 A Indicating Switch

30
ITEM
DESCRIPTION
PART NO.
PER
UNIT
**12 POINTER ASSY.:
1
WHITE
0288-0030B
BLACK
0288-0031B
13 PLATE SCREW:
LOW OR HIGH ALARM (SINGLE)
0317-0012C 1
DUAL ALARM
0317-0012C 2
14 SPRING WASHER:
LOW OR HIGH ALARM (SINGLE)
0257-0019C 1
DUAL ALARM
0257-0019C 2
15 SWITCH PLATE SPACER, HIGH ALARM (SINGLE)
0258-0007C 1
16 LINK PLATE:
LOW OR HIGH ALARM (SINGLE)
0288-0016C 1
DUAL ALARM
0288-0016C 2
17 STRAP:
LOW OR HIGH ALARM (SINGLE)
0288-0017C 1
DUAL ALARM
0288-0017C 2
18 SCREW, 3-48 X 3/16, SST SL., BINDING HD.:
LOW OR HIGH ALARM (SINGLE)
0117-0007J 3
DUAL ALARM
0117-0007J 6
19 SCREW, 4-40 X 1/4 SST SL. ,FL., HD. (WITH RELAY
ONLY):
LOW OR HIGH ALARM (SINGLE)
0112-0037J 2
DUAL ALARM
0112-0037J 4
20 SCREW, 8-32 X 1/4, SST, SL., BINDING HD.:
LOW OR HIGH ALARM (SINGLE)
0117-0016J 1
DUAL ALARM
0117-0016J 2
21 WASHER, #8 FLAT, SST:
LOW OR HIGH ALARM (SINGLE)
0317-0019J 1
DUAL ALARM
0317-0019J 2
22 WASHER, NO. 3 FLAT, SST:
LOW OR HIGH ALARM (SINGLE)
0003-0045K 4
DUAL ALARM
0003-0045K 8
23 GRIP RING (LOW/HIGH ALM.) (SINGLE/DUAL)
0087 -0011 T 1
24 WIRE NUT CONNECTOR (NOT SHOWN):
LOW OR HIGH ALARM (SINGLE) WITH RELAY
0109-0017T 1
DUAL ALARM WITH RELAY
0109-0017T 2
25 MOVEMENT ASSEMBLY
0288-0035B 1
26 LINK ASSEMBLY
0288-0036B 1
27 DRIVE ARM ASSEMBLY: 289A (199 DPU)
0288-0037B 1
28 PLATE, MOUNTING ASSEMBLY
0290-0002B 1
29 STOP, SNUBBER
0226-0028C 2
30 RISER, MOVEMENT
0277-0035C 2
31 RISER, SCALEPLATE
0277-0003C 4
34 BRACKET, STOP
0288-0028C 1
35 BRACKET, TERMINAL BLOCK
0288-0029C 1
36 SCREW, 6-32 X 3/8, SL., RD., HD.
0111-0015J 2
37 SCREW, 4-40 X 3/16 SST, SL., FIL., HD.
0114-0023J 4
