Cameron BARTON 289A - Page 31

31
ITEM DESCRIPTION
PART NO. PER
UNIT
38 SCREW, 4-40 X 3/16, SST., SL, BINDING HD.
0117-0012J 1
39 SCREW, 6-32 X 3/16 SST, SL. BINDING HD.
0117-0013J 4
40 SCREW, 8-32 X 3/16, BIN. HD.
0117-0014J 3
41 GROUND WIRE, GREEN
IT10-1063B 1
42 SCREW, SL, HEX, HD.
0117-1012J 1
43 INT. TOOTH LOCK WASHER
0003-0066K 1
44 EXT. TOOTH LOCK WASHER
0038-0050K 1
45 BLOCK, TERMINAL
0038-0033T 1
46 CASE, EXPLOSIONPROOF
IT10-1091B 1
47 PLATE, SCALE (SEE NOTES BELOW):
1
BLACK
0288-0031C
WHITE
0288-1014C
48 INSULATOR STRIP
0038-1345T 1
49 ADAPTOR, EXPLOSIONPROOF (NOT SHOWN)
S655-0048C 1
50 SCREW, 10-32 X 1/2, FL. HD., SOC.
0240-0019J 2
51 COVER, EXPLOSIONPROOF
IT10-1090B 1
52 SWITCH, WIRED, LOW ALARM:
1
LOW ALARM, SPDT (WITHOUT RELAY)
0257-0009B
LOW ALARM, DPDT (WITHOUT RELAY) #1
0257-0009B
LOW ALARM, DPDT (WITHOUT RELAY) #2
LOW ALARM (WITHOUT RELAY) #1
290B-1009B
0288-0004B
53 SWITCH, WIRED, HIGH ALARM:
1
HIGH ALARM, SPDT (WITHOUT RELAY)
290B-1004B
HIGH ALARM, DPDT (WITHOUT RELAY) #1
290B-1004B
HIGH ALARM, DPDT (WITHOUT RELAY) #2
290B-1011B
HIGH ALARM (WITH RELAY)
290B-1059B
56 PULLER, POINTER (NOT SHOWN)
0163-0005B 1
57 CALIBRATION KIT (NOT SHOWN)
0288-1032B 1
58 NAMEPLATE (NOT SHOWN)
0290-1009G 1
59 RETAINER RING:
SINGLE ALARM 0087-0015T 1
DUAL ALARM 0087-0015T 2
NOTES:
* INDICATES NON-CE USE ONLY.
** NDICATES RECOMMENDED SPARE PART. WHEN ORDERING PARTS, PLEASE SPEC FY THE SERIAL
NUMBER OF THE INSTRUMENT WITH WHICH THEY ARE TO BE USED.
Table 5-2. Model 291B Parts List (cont'd)
