Model 752 and 752A Differential Pressure Transmitters Section 5
Table 5.1—752 and 752A Parts List
ITEM DESCRIPTION PART NO.
PER
UNIT
12* Cap 9A-C0752-1004C 2
14* Junction box 9A-C0752-1114C 1
15 Data plate 9C-C0752-1172G 1
16 I.D. plate, span adjust 9A-C0752-1121C 1
17 I.D. plate, zero adjust 9A-C0752-1122C 1
18* Silicone grease 9A-C0002-1003U A/R
19
Drive screw, 00 9A-C0600-1001J
4
20 Drive screw, #2 9C-C0600-1004J 4
23* Adapter 9A-C0752-1111C 2
24 Lock washer, #6 9A-C0003-0070K 2
25*
Lock washer, 1/4 9A-C0003-0037K
8
26*
Flat washer, 1/4 9A-C0003-1049K
8
29 Tag (not shown) 9A-C0199-0125C 1
30* O-ring, EPT, E740-75, 11/16 x 13/16 9A-C0001-1130R 2
31* Terminal bracket 9A-C0752-1112C 1
32* Pan head screw, 8-32 x 1/4 SST 9A-C0119-0006J 2
33*
Marker strip 9A-C0752-1113C
1
34* Terminal block 9A-C0038-1170T 1
35* Pan head screw, 8-32 x 1/2 SST 9A-C0119-0005J 2
36* Conduit hub 9A-C0024-1006T 2
37* Drain plug 9A-C0186-0001T 1
38* Wire assembly, black 9A-C0752-1120B 1
39*
Wire assembly, red 9A-C0752-1119B
1
40* Port plug, 1/2-in. NPT 9A-C0199-0215C 2
41 DC-550 silicone oil 9A-C0003-1002U A/R
42* Hex head bolt, 1/4-28 x 5/8 (8 ft-lb Torque) 9A-C0116-1007J 4
43* O-ring, cover, EPT 9A-C0001-1105R 1
44 Washer, at, #6, SST
9A-C0003-0040K
1
45* Housing O-ring, EPT, E740-75, 1-3/4 X 1-7/8
9A-C0001-1054R
2
46* Housing, 1/2 × 1/4 NPT Ports
9A-C0764-1025C
2
47*
Housing Cap Screws; 3/8-24×1-1/2 SST (40 ft-lb
Torque)
9A-C0220-1028J
8
