CONTROLS/INSTRUMENTS
rmo2008-004-400_a
1. Upshift
2. Downshift
This shifts sequentially from one gear
to the next. Release the selector after
shifting.
To shift through multiple gears, use the
selector multiple times.
To shift into neutral from first gear or
reverse, briefly press or pull the gear
selector. A longer activation will shift
over neutral. Refer to the
SHIFTING
subsection for detailed instructions.
When the gearshift selector is re-
leased, the mechanism resets for the
next shift up or down.
If operator does not downshift when
slowing down and engine RPM drops
below a threshold value, the gearbox
will automatically downshift to the
next available gear.
If the engine is started with the gear-
box in gear, it will automatically shift to
neutral position.
6) Brake Pedal
The brake pedal is in front of the right
footrest. Press it down to operate.
This pedal brakes all three wheels.
rmo2008-001-008_a
1. Brake pedal
2. Footpeg
7) Parking Brake Pedal
The parking brake pedal is behind the
operator's left footpeg.
rmo2008-001-079_a
1. Parking brake pedal
With the vehicle stopped, press it
down firmly until it locks to apply the
parking brake. Firmly press the pedal
down a second time to release the
parking brake.
rmo2008-001-080_a
1. Engaging/disengaging parking brake pedal
WARNING
Do not use the parking brake to
slow or stop the vehicle; you could
lose control, spin, tip or roll over.
Warn passenger not to touch it
with their left foot.
_______________
13
