CONTROLS/INSTRUMENTS
10) Engine Temperature
Bar gauge that continuously indicates the engine coolant temperature.
11) Digital Speedometer
In addition of the analog type speedometer, vehicle speed can also be indicated via
this display.
Speed can be displayed in kilometers (Km/h) or miles (MPH) per hour. To change
units, refer to
SETTING METRIC/IMPERIAL UNITS
.
Startup and Shutdown
Any time the ignition switch is set to ON after having been in the OFF position for
five minutes or more, the main digital display will scroll the following message:
– BEFORE OPERATING READ THE SAFETY CARD ABOVE THEN PRESS _M_
BUTTON.
NOTE: Acknowledge this message to allow engine starting.
Digital Display Information
WARNING
Do not adjust the display while riding. You could lose control.
Main Display Functions
Pressing the SET (S) button will scroll through the different functions.
FUNCTION SEQUENCE INFORMATION DISPLAYED
Outside temperature
XX °C (Celsius)
XX °F (Fahrenheit)
Tachometer (revolutions per minutes) XXXX RPM
Secondary Display Functions
Pressing the MODE (M) button will scroll through the different functions.
FUNCTION SEQUENCE INFORMATION DISPLAYED
Clock
XX:XX (24:00 time base)
XX:XXAorP(12:00AM/PMtimebase)
Cumulative distance odometer
XXXXX.X Km or mi
Trip distance — odometer A (TRIP A) XXXXX.X Km or mi
Trip distance — odometer B (TRIP B) XXXXX.X Km or mi
Trip time chronometer (HrTRIP) XXXXX.X
Engine time chronometer (Hr) XXXXX.X
To reset any trip functions, push and
hold the MODE (M) button for three seconds.
20
