Installation, use and maintenance instruction manual ▪ Ed. 07/2018 Rev. 00
INSTALLATION ON SUPPORT STRUCTURE
The appliance must be mounted on a support structure, made of material resistant to heat and with all of
the sturdiness requirements indicated by the technical sector standards (for example EN14749). The work
table must be perfectly horizontal and perpendicular to all surrounding vertical panelling. The area near
the appliance could get very hot. Pay the utmost attention and do not place sockets, other household
appliances, power cables, piping and any other heat-sensitive or flammable material in this area.
ATTENTION!
The appliance must be installed in a room without air draughts which can have a negative
effect on combustion. The chosen installation position must also prevent the accumulation of
unburnt gases.
Comply with the sizes indicated in this manual. Any deviation could cause the temperature to rise excessively.
The surrounding surfaces must be able to withstand temperature rises admitted by standard EN30-1-1 and in
compliance with the design of this unit. All combustible material, such as curtains and shelves, must be kept
far away from the appliance. Check the admissible temperature of the materials used for the surrounding
surfaces to guarantee their compliance with the requirements of EN30-1-1.
RECESSED HOLE
The support structure must be provided with a suitable recessed hole. For information regarding the
dimensions of the hole of your model, refer to the table below and follow the drawings in the technical data
sheets of each model in the first section of this manual.
