SPARE PARTS - FC1348
The column "Pos." refers to the exploded drawing "TYPE FC1348" on page 44.
VERSION S - MANUAL LIGHTING
code
component
pos.
component
2000008 4
Hinge for glass lids
3000002 3
Glass FC1348
3000072 22
Rubber bushing for pan holders
2000096 1
SR stainless steel pan support for steel hob units
2000095 1
AUX stainless steel pan support for steel hob units
4000170 2
Glass lid cable gland
4000008 23
Standard black knob
4000031 30
Universal nut for thermocouple
4000069 28
Thermocouple for fast-on magnet cock
4000181 17
Burner spreader for 3rd series SR burner
4000185 18
Ø 70 enamelled cover 3rd series SR burner
4000182 19
Burner spreader for 3rd series AUX burner
4000184 20
Ø 50 enamelled cover 3rd series AUX burner
7000138 -
Glass lid flame label
4000229 32
5 x 6 CH screw to secure the hinge and silentblock
E VERSION - ELECTRONIC LIGHTING
code
component
pos.
component
4000015 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 27
Burner lighting glow plug L350
4000137 31
Clip for glow plug
SPARE PARTS - FC1349
The column "Pos." refers to the exploded drawing "TYPE FC1349" on page 45.
VERSION S - MANUAL LIGHTING
code
component
pos.
component
2000008 4
Hinge for glass lids
3000410 3
RH glass lid FC1349
3000411 3
RH glass lid FC1349
3000083 22
Tall rubber bushing for pan holders
3000073 1
Wire pan holder for AUX burner
3000074 1
Wire pan holder for SR burner
3000454 6
Silentblock Ø 15
4000026 29
2nd series lid stud bolt
4000170 2
Glass lid cable gland
