CAN FC Series - Spare Parts for FC1352

61
ENGLISHENGLISH
Installation, use and maintenance instruction manual ▪ Ed. 07/2018 Rev. 00
7000138 -
Glass lid flame label
4000229 32
5 x 6 CH screw to secure the hinge and silentblock
E VERSION - ELECTRONIC LIGHTING
code
component
pos.
component
4000319 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 -
Burner lighting glow plug L350
4000137 -
Clip for glow plug
SPARE PARTS - FC1352
The column "Pos." refers to the exploded drawing "TYPE FC1352" on page 47.
VERSION S - MANUAL LIGHTING
code
component
pos.
component
2000008 4
Hinge for glass lids
3000348 3
Glass lid FC1352
3000083 22
Tall rubber bushing for pan holders
3000073 1
Wire pan holder for AUX burner
3000074 1
Wire pan holder for SR burner
3000453 6
Silentblock Ø 11
4000260 23
Black/chrome knob Ø 34
4000031 30
Universal nut for thermocouple
4000069 28
Thermocouple for fast-on magnet cock
4000295 28
Long thermocouple for fast-on magnet cock
4000182 19
Burner spreader for 3rd series AUX burner
4000184 20
Ø 50 enamelled cover 3rd series AUX burner
4000181 17
Burner spreader for 3rd series SR burner
4000185 18
Ø 70 enamelled cover 3rd series SR burner
7000138 -
Glass lid flame label
4000229 32
5 x 6 CH screw to secure the hinge and silentblock
E VERSION - ELECTRONIC LIGHTING
code
component
pos.
component
4000015 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 27
Burner lighting glow plug L350
4000137 31
Clip for glow plug
